  • nVent HOFFMAN PTHW482436G2

    nVent HOFFMAN PTHW482436G2

    nVent PTHW482436G2

    Hoffman PROTEK® PTHW482436G2 DWDH2 Double Hinged Window Door Electrical Cabinet, 48.54 in L x 23.62 in W x 36.02 in D, NEMA 4/4X/12/IP66/55 NEMA Rating, Glass/Steel

    • Brand: nVent HOFFMAN
    • MPN: PTHW482436G2
    • UPC: 783510291259
    • UNSPSC: 43223306
    • ASPN: HOFFPTHW482436G2
    • Min. Order Qty: 1
    • Qty. Interval: 1
    Price: loading
    nVent HOFFMAN PTHW482436G2

    Hoffman PROTEK® Electrical Cabinet, Double Hinged Window Door, Series: DWDH2, 48.54 in Length, 23.62 in Width, 36.02 in Depth, NEMA 4/4X/12/IP66/55, 1 Door, Rack Unit: 26U, 1.11 in THK Door, Keyed Wing Knob Lock, 3.6 A, 115 VAC, 350 lb, Wall Mount, 52 to 131 deg F, Glass/Steel, Polyester Powder Painted, Light Gray

    Type : Double Hinged
    Series : DWDH2
    Length : 48.54 in
    Width : 23.62 in
    Depth : 36.02 in
    NEMA Rating : NEMA 4/4X/12/IP66/55
    Rack Unit : 26
    Capacity : 350 lb
    Material : Steel/Glass
    Color : Light Gray
    • Front and rear access to 19 in rack equipment provided by three part design door, center section and wall section
    • Solid door provides complete physical and visual protection
    • Window door, made of scratch-resistant safety glass, provides visual monitoring of internal equipment while maintaining equipment protection
    • All seams are fully welded and ground smooth
    • Doors, center section and wall section are provided with ground studs to facilitate proper bonding and grounding of the cabinet
    • Premium seamless, foam in place gasket prevents contaminants from entering the cabinet
    • Stainless steel cabinet is provided with a quarter turn slotted latch
    • One set of plated, self-grounding, tapped 10-32 rack angles per EIA universal spacing standards, which can be adjusted front to back, is provided with each center section of the cabinet
    • On 28 in (700 mm) wide enclosures, a 4 in vertical cable manager with composite fingers is provided on hinge side of cabinet
    • Keylocking wing knob is included on painted steel offering, providing access control to the cabinet
    • pdf Specification Sheet https://www.frenchgerleman.com//ASSETS/DOCUMENTS/ITEMS/EN/https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_358f56e74548f99ea3d643986d5c6ded2d4b4e50680b1eb2eeac78e15e4ee54a.pdf
    • pdf Warranty Information https://www.frenchgerleman.com//ASSETS/DOCUMENTS/ITEMS/EN/https://assets.unilogcorp.com/2/ITEM/DOC/IDW_DOCUMENT_6fd9c4fc72479d8cb85137c143238fe864b95a3232fc96fd37ccbb84e0f67cc8.pdf
