Thomas & Betts 54942BE
Color-Keyed® 54942BE 54900 1-Hole Non-Insulated Compression Lug, 2 AWG Stranded Copper Conductor, Die Code: 33, 5/16 in Stud, Copper
- Brand: Color-Keyed®
- MPN: 54942BE
- UPC: 786210886350
- UNSPSC: 39121405
- ASPN: TNB54942BE
- Min. Order Qty: 1
- Qty. Interval: 1
Color-Keyed® Compression Lug, 1-Hole Non-Insulated, Series: 54900, Stranded Copper Conductor, 2 AWG Conductor, Die Code: 33, 600 VAC to 35 kV, 5/16 in Stud, Straight Tongue, 0.88 in L x 0.59 in W x 0.11 in THK Tongue, 2.03 in Overall Length, Blind End/Long Barrel, 0.41 in Dia Barrel, Specifications: 3/8 in Center of Hole to Tongue End, Tin Plated, 0.344 in Mounting Hole, Copper, Brown
| Type | : | 1-Hole |
| Series | : | 54900 |
| Conductor Type | : | Copper |
| Conductor Size | : | 3 to 2 AWG |
| Die Code | : | 33 |
| Voltage Rating | : | 600 to 35000 VAC |
| Stud Size | : | 5/16 in |
| Tongue Size | : | 0.88 in L x 0.59 in W x 0.11 in THK |
| Overall Length | : | 2.03 in |
| Barrel Size | : | 0.41 in Dia |
| Material | : | Copper |
- Connectors have colored bands or colored dots that correspond to color markings on the dies
- Color-Keyed® connectors are banded by colored stripes or engraving to indicate location of die on connector for compression
- Connection by compression
- High quality connection at a low installed cost
- High conductivity wrought copper construction
- 3/8 in hole center to end
- Tin plated finish
-
